Ironworker Machine

Multi Cutter Iron Worker – Model QA32-8BVersatile and Heavy-Duty Metalworking Machine for Fabrication and Industrial UseThe QA32-8B Multi Cutter Iron Worker is a multi-functional steel processing machine designed for precision cutting, punching, notching, and shearing of various metal materials. Widely used in steel fabrication, shipbuilding, mechanical workshops, and metal structure construction, this machine is engineered to perform multiple operations with high efficiency, accuracy, and minimal setup time. Built with a rugged steel frame and industrial-grade tooling, the QA32-8B is a reliable and essential asset for modern fabrication shops that demand productivity and durability.Key Features:Multi-Functional Operation:The QA32-8B combines punching, flat bar shearing, angle cutting, round/square bar shearing, and notching in a single compact machine. This significantly reduces the need for multiple individual machines and saves valuable workshop space.Heavy-Duty Steel Construction:Crafted from industrial-grade materials, the frame and body ensure stable operation and long service life even under continuous heavy-duty usage. The rigid structure reduces vibration, enhancing cutting precision and tool life.Hydraulic Operation System (Optional):Though standard models are often mechanical, some configurations may include hydraulic assist for smoother operation and increased pressure control during punching and cutting processes.Quick Tool Change System:The machine allows for rapid tooling changes, improving turnaround time for different operations and reducing downtime during production.Precision Punching and Shearing:Equipped with hardened steel dies and blades, the QA32-8B delivers clean, accurate cuts and holes in materials such as mild steel, stainless steel, aluminum, and other metals.User-Friendly Controls:Designed with operator ease in mind, it features simple mechanical levers and switches for activating different functions. Safety guards and foot-pedal controls may also be included for hands-free operation and increased safety.Applications:The QA32-8B Iron Worker is perfect for a wide range of metal fabrication and manufacturing operations, including:Structural steel processing and fabricationIndustrial equipment manufacturingShipbuilding and marine industriesBridges, towers, and infrastructure projectsMetal workshop operations and general fabricationTypical Technical Specifications:Specification DetailsModel Name/Number QA32-8BOperation Type Mechanical (hydraulic optional in some variants)Punching Capacity Up to 25 mm diameter in 8 mm thick mild steelFlat Bar Shearing Up to 200 × 8 mmAngle Iron Cutting Up to 63 × 6 mm at 90°Round Bar Cutting Up to 30 mmSquare Bar Cutting Up to 25 mmNotching Capacity V-notch: 90° – 50 × 40 × 6 mmMotor Power Approx. 3 kW – 4 kW (varies by configuration)Voltage 3 Phase, 415V / 50HzMachine Weight Approx. 600 – 750 kgDimensions (L x W x H) Approx. 1100 x 700 x 1500 mmNote: Specifications may vary slightly based on manufacturer or custom features.Advantages:Five-in-one functionality for increased productivityReduces labor time and workshop spaceAccurate, clean cuts and punches for professional fabricationBuilt for long-term industrial use with minimal maintenanceCost-effective solution compared to purchasing separate machinesAdaptable to various fabrication environments, from small shops to large manufacturing unitsSafety & Maintenance Guidelines:Always wear appropriate PPE including gloves, goggles, and safety boots.Regularly inspect blades, dies, and moving parts for wear or damage.Keep the machine clean and well-lubricated for optimal performance.Use only material within rated thickness and hardness to avoid damage.Ensure all safety guards and foot-pedals are functional and correctly installed.The Pinnacle QA32-8B Multi Cutter Iron Worker is a versatile and powerful fabrication tool, ideal for professionals who require multiple metal processing capabilities in a single, compact, and efficient unit. Whether used in a workshop or on an industrial job site, it delivers consistent results and improves productivity across a wide range of applications.

Multi-Purpose Ironworker MachineVersatile and Efficient Solution for Steel Fabrication, Cutting, and PunchingThe Multi-Purpose Ironworker Machine is a heavy-duty, industrial-grade machine designed to handle a variety of metalworking tasks such as punching, shearing, notching, and bending. Known for its versatility and precision, this machine is a crucial tool for steel fabricators, construction contractors, and manufacturing facilities that require high-performance metal processing for structural components, beams, plates, and various metal parts. Combining multiple operations in one compact system, it not only saves valuable space but also reduces operational time and costs, making it ideal for industrial workshops, metalworking shops, and construction projects.Key Features:Multi-Functionality:The Multi-Purpose Ironworker Machine integrates several functions, including punching, shearing, notching, angle cutting, and bar cutting, into one powerful machine. This makes it highly adaptable to various metalworking tasks, eliminating the need for multiple machines.Powerful Hydraulic System:Equipped with a robust hydraulic power unit, the machine delivers high force and smooth operation for all functions. It ensures efficient and accurate punching, cutting, and shearing of different materials, such as mild steel, stainless steel, and aluminum.Heavy-Duty Construction:Built with a sturdy frame, reinforced components, and high-quality dies, the machine is designed to withstand continuous use in industrial environments. Its rigid structure minimizes vibration, which enhances the precision of every operation.Precise Cutting and Punching:With the ability to cut thick plates and bars and punch holes up to large diameters, the machine ensures clean and accurate results every time. It is capable of cutting materials with precision, providing straight edges and smooth holes in various thicknesses.User-Friendly Controls:Featuring easy-to-operate controls, the machine allows operators to quickly set the desired function, adjust settings, and execute tasks without complicated setups. Foot pedals and manual levers enable hands-free operation, providing better control and safety.Wide Range of Tools and Dies:The machine comes with a variety of standard and customizable dies and tools, enabling you to handle a wide range of material thicknesses and geometries. It allows you to adapt to different requirements on-site or in the workshop.Safety Features:Designed with operator safety in mind, the machine is equipped with safety guards, emergency stop buttons, and automatic shutoff features that minimize the risk of accidents during operation. The use of foot pedal activation ensures that the operator maintains a safe distance from moving parts during use.Applications:The Multi-Purpose Ironworker Machine is ideal for a variety of applications, including:Steel and metal fabrication for structural componentsManufacturing and pre-fabrication of metal framesConstruction and bridge buildingShipbuilding and industrial applicationsProduction of metal gates, fences, and railingsRepair and maintenance of metal partsCustom metalworking and sheet metal productionTypical Technical Specifications:Specification DetailsMachine Type Multi-Purpose Ironworker MachineHydraulic System Hydraulic Press with Power UnitMax Punching Capacity Up to 32 mm diameter (mild steel)Max Shearing Capacity Up to 16 mm thick (mild steel plates)Max Notching Capacity V-notch: 40 × 40 mmMax Bar Cutting Capacity Round Bar: Up to 25 mmMotor Power 5 HP to 15 HP (varies by model)Voltage 3 Phase, 415V / 50HzWeight 1,000–2,000 kg (depending on configuration)Dimensions (L x W x H) Approx. 2,000 x 1,000 x 1,500 mmMachine Speed Adjustable cutting and punching speedsNote: Specifications may vary depending on the model and custom features.Advantages:Multiple Functions in One Machine – Save time and space by consolidating cutting, punching, shearing, and notching into a single unit.High Efficiency and Precision – The hydraulic system and robust frame offer accurate, clean cuts with minimal material wastage.Heavy-Duty Durability – Designed for continuous operation, the machine can handle tough working conditions in industrial and heavy fabrication environments.Cost-Effective Solution – Reduces the need for multiple individual machines, lowering overall costs while enhancing productivity.Customizable Dies and Tools – Accommodates a wide range of materials, thicknesses, and shapes, improving operational flexibility.Enhanced Operator Safety – Equipped with safety features like emergency stops, foot pedal operation, and protective shields for safe operation.Safety & Maintenance Guidelines:Always ensure the machine is operated by trained personnel and follow all safety protocols.Perform regular maintenance checks on hydraulic fluid, cutting blades, and dies to ensure optimal performance.Keep the cutting edges sharp and free from debris to maintain cutting precision.Replace worn or damaged parts immediately to prevent further damage or unsafe operation.Always wear appropriate PPE, including gloves, eye protection, and safety shoes.Regularly clean the machine to ensure smooth operation and prevent buildup of material debris.The Multi-Purpose Ironworker Machine is an indispensable tool for metal fabrication, offering unmatched versatility, precision, and durability. It enhances productivity, reduces operational costs, and streamlines workflow in workshops and fabrication facilities. Whether you're cutting, punching, or shearing metal, the Multi-Purpose Ironworker Machine is engineered to deliver exceptional performance on every job

Universal Ironworker Machine – All-in-One Metal Fabrication Solution for Punching, Shearing, Bending, and NotchingThe Universal Ironworker Machine is a multi-functional, heavy-duty metalworking machine designed to perform a wide range of fabrication tasks including punching, shearing, bending, notching, and cropping with precision and efficiency. Ideal for workshops, fabrication plants, and industrial settings, this versatile machine integrates several operations into a single, space-saving unit—making it an essential tool for metal fabricators and structural engineers.Key Features:5-in-1 Functionality: Combines five essential fabrication capabilities—punching, flat bar shearing, angle cutting, round/square bar shearing, and notching—to handle a wide variety of tasks with speed and accuracy.Robust Hydraulic System: Powered by a high-pressure hydraulic system, the machine delivers powerful force and smooth operation for consistent and clean results, even on thicker materials.Precision Punching Station: Capable of punching clean holes in sheet metal, plates, angle iron, and channel sections with minimal burr or distortion. Interchangeable punch and die sets make it adaptable for various hole sizes and shapes.Efficient Shearing Stations:Flat Bar Shearing: Cuts flat bars to length with precision.Angle Shearing: Cuts standard angle iron cleanly without deformation.Round/Square Bar Shearing: Cuts round and square stock cleanly and quickly.Integrated Notching Station: Allows precise notching of sheet metal, angle sections, and plates for joints, fittings, and customized assemblies.Optional Bending Attachments: Some models include or allow attachment of bar or sheet bending tools to further expand the machine’s functionality.Durable Construction: Built with a heavy-duty steel frame and industrial-grade components to withstand rigorous use and provide long-lasting reliability.User-Friendly Controls: Features foot pedal operation or manual lever control for enhanced operator safety and hands-free use at the punch or shear stations.Safety Features: Includes guards, emergency stops, and interlocks to protect operators during operation.Technical Specifications (Typical):Type: Hydraulic or Mechanical Universal IronworkerTonnage: Common capacities range from 40 to 150 tonsPunching Capacity: Up to 32 mm hole in 20 mm thick mild steel (varies by model)Flat Bar Shear Capacity: Typically up to 300 mm x 20 mmAngle Cut Capacity: 90° and 45° cuts on standard angle ironRound/Square Bar Shear Capacity: Up to 40 mm diameterNotching Capacity: V-notch and rectangular notch; up to 100 mm x 8 mmMotor Power: Typically ranges from 5 to 15 HPOperation: Hydraulic with electrical controls and foot pedalApplications:Structural steel fabricationMetal fabrication workshopsManufacturing of frames, gates, and metal furnitureConstruction, shipbuilding, and heavy machinery productionMaintenance departments and repair shopsThe Universal Ironworker Machine is a workhorse for modern metal fabrication, offering unmatched versatility, reliability, and performance in a compact design. Whether you're cutting, punching, or notching, this all-in-one machine saves space, reduces processing time, and lowers production costs—making it a valuable asset for any metalworking operation.

Hydraulic Ironworker Machine – Versatile Heavy-Duty Metal Fabrication ToolThe Hydraulic Ironworker Machine is a multifunctional metalworking powerhouse designed to perform a variety of cutting, punching, notching, and bending tasks with exceptional precision and efficiency. Powered by a robust hydraulic system, this machine is widely used in fabrication shops, manufacturing units, and construction sites to streamline steel processing and fabrication workflows.Key Features:Multifunctional Capability: Combines several metalworking operations into a single machine including:Shearing (cutting) of steel plates, angles, bars, and flat materialsPunching holes of various shapes and sizes in metal sheets and profilesNotching to create precise cuts or remove sections from metal profilesBending of flat bars and plates to desired anglesPowerful Hydraulic System: Equipped with a high-pressure hydraulic pump and cylinder system, providing consistent and adjustable force for clean cuts and accurate punching without distortion or material damage.Heavy-Duty Construction: Built from reinforced steel frames and components to withstand rigorous industrial use, ensuring durability and long service life under continuous operation.Precision and Efficiency: High accuracy in punch positioning and shear cutting with adjustable back gauges and guides, enabling repeatable and precise fabrication for complex jobs.User-Friendly Controls: Simple operation panel with manual or semi-automatic controls for easy setup and operation, reducing operator fatigue and increasing productivity.Interchangeable Tooling: Compatible with a wide range of punches, dies, blades, and accessories for different metals, thicknesses, and shapes, enhancing versatility.Safety Features: Includes emergency stop buttons, protective guards, and safety interlocks to protect operators during use.Technical Specifications (Typical):Power Source: Hydraulic pump powered by electric motor (varies by model, commonly 5–15 HP)Shearing Capacity: Steel plate thickness from 6 mm up to 25 mm (varies by model)Punching Force: Up to 100 tons or more, capable of punching holes in metal sheets and profilesPunch Hole Diameter: Varies with tooling, commonly up to 40 mm or largerNotching Capacity: Up to 120 mm square notch in mild steelBending Capacity: Typically bends flat bars up to 20 mm thicknessMachine Weight: Several hundred kilograms depending on configurationDimensions: Varies by model and tooling optionsApplications:Structural steel fabrication and assemblyManufacturing of metal frames, gates, and railingsProduction of industrial machinery componentsCustom metal fabrication shopsConstruction and maintenance workshopsThe Hydraulic Ironworker Machine is an essential tool for professionals requiring a robust, reliable, and versatile metalworking solution. By integrating multiple fabrication processes into one machine, it significantly reduces production time, labor costs, and floor space requirements, all while delivering precision and consistent results.
